4IRT800900 - SATA IRT Spotcure DRAFT UV Drying Lamp

• Brand: IRT (Hedson)
• Reference: 4IRT800900 (SpotCure²)
• Type: UV-A LED drying lamp for bodywork touch-up
• Power Supply: 100–240 V AC, 300–400 W
• Wavelength: 395 nm (targeted UV-A)
• LED: 132 LEDs with individual optics for uniform intensity
• Risk Group: EN 62471 / EN 62473 – category 3
• Cable Length: 10 m
• Optional Accessory: stand or tripod for stationary use

Main Advantages

• Rapid Drying: reduces curing time from several minutes to a few seconds depending on the UV product.
• Radiation Uniformity: even coverage over a wide work area thanks to multi-LED optics.
• Active Cooling: regulated ventilation and integrated thermal protections for safe continuous use.
• Workshop Ergonomics: compact, lightweight design and long cable (10 m) for optimal user comfort.
• Safety Compliance: complies with photobiological standards EN 62471/62473; UV glasses and eye protection provided depending on version.

Usage Tips

• Preparation: mask surrounding areas, degrease and prepare the substrate according to the product TDS.
• Working Distance: approximately 45 cm for optimal balance between covered surface and light intensity.
• Application: apply the putty or UV primer, allow to level, then expose in slow, regular passes until fully cured.
• Control: check hardness before sanding (complete cooling), sand with P600–P800 before painting.

Safety

• Mandatory use of UV protective glasses, gloves, and respiratory protection.
• Never look directly at the light source during operation.
• Adhere to exposure times and recommended power according to the safety data sheet (SDS).
• Demarcate the exposure area when using in the workshop.

Compact, powerful, and reliable, the IRT SpotCure² 4IRT800900 lamp is the reference solution for workshops aiming to optimize productivity and the quality of their UV product drying. It combines performance, safety, and repeatability for professional results in record time.
